Available as either single or dual channel units, the Trilogy 410 Series beltpacks are designed for 4 wire operation providing a convenient portable connection to any Trilogy intercom system. Each is fitted with a momentary ‘push to talk switch’ plus individual volume control(s) for the incoming audio level. These high performance beltpacks are suited for use with any quality low impedance headset equipped with dynamic microphone depending on the model.
Key benefits:
|
4410-50-12 |
||
|---|---|---|
|
No. of input channels (from matrix) |
1 |
|
|
Fixed Connector type |
XLR6 Male |
|
|
Mating Connector type required |
XLR6 Female |
|
|
Supply voltage required |
+15V |
|
|
Headset connector (socket) |
XLR5 Female |
|
|
410-50-13 |
||
|---|---|---|
|
No. of input channels (from matrix) |
2 |
|
|
Fixed Connector type |
Hirose 12 Way Plug RM15TRD-12P |
|
|
Mating Connector type required |
Hirose 12 Way Socket RM15TPD-12S |
|
|
Supply voltage required |
± 15V |
|
|
Headset connector (socket) |
XLR5 Female |
|
